Materials of Construction |
Filter Media | PES/Nylon66/PTFE/PP/GF/PVDF |
Support & Housing | PP |
Sealing technology | Thermal Bonding, No Adhesives |
Dimensions |
Outer Diameter | Φ65: PTFE Φ60: PES/Nylon66/PP/GF/PVDF |
Inlet/Outlet | 7~13 mm stepped hose barb connection with 6:100 Luer slip |
Filtration Area, ft2 |
≥ 0.021 |
Pore Size, μm |
Please refer to Ordering Information. |
Bubble Point & Air Flow Rate (PTFE 0.22 μm, 0.01 μm for air & gas) |
Bubble Point: ≥ 900 mbar with 60/40% IPA/water Air Flow Rate: ≥ 25 L/min at 1 bar |
Maximum Operating Pressure |
Forward: 3.5 bar @ 23℃ and 3.0 bar @ 60℃ for liquid; 3.0 bar @ 23℃ and 2.5 bar @ 60℃ for air & gas. |
Bacterial Retention (for 0.22 μm PES/PTFE ) |
Passed the bacterial challenge testing using Brevundimonas diminuta(ATCC19146) at a minimum challenge concentration of 1 x 107 CFU/cm2. |
Biological Safety |
Meets GB/T 14233.2 of Chinese National Standard for Safety Tests. |
Sterilization |
By EO or 3 autoclave cycles of 30 min at 123 ℃; steam-in-place sterilization not recommended. |
Good Manufacturing Practices |
