Production capacity
Window “out of measure” 25/30 pcs. in 8 hours
Door 25/30 pcs. in 8 hours
Boxed door 100 pcs. in 8 hours (only squaring)
Please ask for possibility more included tools equipment
Technical details summary
Cut-off saw, completely retractable inside its guard
*****
> cut-off saw manual controlled: 8 position
> number of tools: 1 pcs.
> number of revolutions of spindle: 3000 rpm
> tools diameter maximum: 400 mm
> motor power: 3 kW
Length fence
*****
> manual length fence from 270 to 2800 mm
Mobile carriage with left/right travel giving just one pass beneath the tools
*****
8 position chip-breaker drum with manual positioning
*****
Tenoning spindle
*****
> number of tools: 5 pcs.
> spindle stroke: CNC, electronic free programmable
> number of revolutions of spindle: 3500 rpm
> spindle diameter: 50 mm
> tool clamping length: 320 mm
> tools diameter maximum: 320 mm
> motor power: 7, 5 kW
1st moulding spindle
*****...............................
> number of tools: 4 pcs.
> spindle stroke vertical: CNC, electronic free programmable
> number of revolutions of spindle: 6000 rpm
> spindle diameter: 50 mm
> tool clamping length: 320 mm
> tools diameter maximum: 240 mm
> motor power: 5, 5 kW
Guide fences with automatic alignment
*****
