*Technical data
V10 GNSS RTK Serveying Equipment/GPS
100 channels can be used on URS data transfer station
V10 GNSS RTK Serveying Equipment/GPS
External Communication Module
> Available for UHF radio or URS data transfer station
> 16 channels can be used on UHF radio, High or Low frequency alternative
> 100 channels can be used on URS data transfer station, maximum transmission distance is 50km
>> Technique Parameter of V10 GNSS RTK Serveying Equipment/GPS
1, Receiver Component
TECHNICAL SPECIFICATIONS
> 220 Channels:
GPS: Simultaneous L1 C/A, L2E, L2C, L5
GLONASS: Simultaneous L1 C/A, L1 P,
L2 C/A (GLONASS M Only), L2 P
SBAS: Simultaneous L1 C/A, L5
GIOVE-A: Simultaneous L1 BOC, E5A, E5B, E5AltBOC1(optional)
GIOVE-B: Simultaneous :L1 CBOC, E5A, E5B, E5AltBOC1(optional)
GALILEO: (Upgraded to reserve)
> Advanced Trimble Maxwell 6 Custom Survey GNSS Technology
> High precision multiple correlator for GNSS pseudorange measurements
> Very low noise GNSS carrier phase measurements with < 1 mm precision in a 1 Hz bandwidth
> Proven Trimble low elevation tracking technology
Initialization time3 . . . . . . . . ......................typically < 10 seconds
Initialization reliability3 . . . . . . . . . . . . . . . . >99.9%
> 1 Hz, 2 Hz, 5 Hz, 10 Hz, 20 & 50 Hz positioning outputs (Defaults 10HZ)
> Up to 50 Hz raw measurement & position outputs
Reference outputs . . . . . .CMR, CMR+, RTCM 2.1, 2.2, 2.3, 3.0 , 3.1
Navigation outputs . . . . . . ASCII: NMEA-0183 GSV, AVR, RMC, HDT, VGK, VHD, ROT, GGK, GGA, GSA, ZDA, VTG, GST, PJT, PJK, BPQ, GLL, GRS, GBS and Binary: Trimble GSOF
2, Internal UHF Radio Component
> Frequency bands: 225-235MHz, 450-470MHz, meeting different requirements.
> 19.2k bps wireless data rate
> 16 flexible switching channels (direct-switched of the panel buttons without controller or computer), users can alter the frequency table
