Product Description

• Brand Name: Xinsheng
• Technical parameters

  Model	DAC50	DAC100	DAC150	DAC200	DAC300	DAC400
  Specifications of column tube (ID*length) mm	50*650(Standard)	100*650(Standard)	150*650(Standard)	200*650(Standard)	300*650(Standard)	400*650(Standard)
  Overall Size(W*D*H) mm	560*560*2050	600*600*2280	630*720*2300	700*740*2600	900*920*2900	1200*1200*3000
  Liquid contact material	PTFE/316L
  Packing method	Down packing
  Distribution form	H-TREE distribution
  Effective packing height	≤450mm
  Frit aperture	2um
  Weight (kg)	80	140	260	400	870	1400
  Pressure	10MPa




  Model	DAC450	DAC600	DAC700	DAC800	DAC1000	DAC1200
  Specifications of column tube (ID*length) mm	450*650(Standard)	600*650(Standard)	700*650(Standard)	800*800	1000*800	1200*1000
  Overall Size(W*D*H) mm	1100*1300*3200	1300*1500*3600	1400*1600*3800	1600*1800*4000	1800*2200*4300	2000*2200*4500
  Liquid contact material	PTFE/316L
  Packing method	Down packing
  Distribution form	H-TREE distribution
  Effective packing height	≤450mm
  Frit aperture	2um, 15um(Standard)
  Weight (kg)	2300	4500	5600	7000	9000	12000
