Product Description

• JSP Automatic Rotary Cylinder Screen Printing machine
  Features: The machine is equipped with advanced design and production technologies. The main components used for the import of components, after many years of continuous improvement, the printing function in different fields play a role. The high-speed and high-precision machine for automatic sheet Screen Printing Presses, can adapt to 0.15-0.8mm thickness of sheet, plastic films, metal coating materials leaflets monochrome and multicolor-color printing. The machine is used PLC program to control, it is simple for operate. The machine has two feed devices: continuous feeding and sheet-by-sheet feeding, which can be chosen subject to the material. According to the different characteristics of the printing, the machine can be used with the flip-drying machine, ultraviolet dryer, infrared and UV dryer on-line. The machine is used widely, can be printed cigarette packs and other packaging, and offset, transfer paper, signs, advertisements, soft circuit boards and other kinds of printing.
  技术参数Technical parameter:

  机型Model	JSP720	JSP780	JSP1020
  最大纸张尺寸Max. paper size(mm)	720×520	780×540	1020×740
  最小纸张尺寸Min. paper size(mm)	350×270	350×270	560×350
  最大印刷尺寸Max. printing area(mm)	720×500	780×520	1020×720
  纸张厚度paper thickness(g/m2)	120—350	120—350	120—350
  网框尺寸frame size(mm)	880×880	940×940	1280×1140
  最高印刷速度printing speed(p/h)	1000—3600	1000—3300	1000—3000
  总功率total power(kw)	8.2	9	11
  重量weight(kg)	3500	4000	5500
  外形尺寸dimension(mm)	3760×1960×1270	3760×1960×1270	4500×2600×1300

Company Profile

• Shanghai JIAYOU machinery.,ltd
• [ China ]
• This company is registered as a free member and is not verified or authenticated by Tradekey.com
• Introduction of company   Shanghai JIAYOU Machinery CD., LTD. is a professional automatic screen printing press in the research, development, production and sales of integrated enterprise. The company has a strong technical force and a complete production capacity, its exquisite products deeply users welcome. Since its founding companies focus on branding, its purpose for the quality of our p...


Basic Information

• Company Products / Services: auto screen printing machine
• Year Established: 2005
• Number of Employees: 1-5
